Folders
Web Offset — Finishing
Five folder configurations for Orient web-offset presses, spanning 4 to 12 webs and speeds up to 50,000 cph — from economical 1:2 Standard to the flagship X-Press 1:2:2.
Maximum SpeedUp to 50,000 cph
Key Features
- →Jaw 1:2 Standard — economical rugged 1:2 folder, 4 webs, 16,000 cph
- →Jaw 1:2 Super — double RTF roller, 6 – 8 webs, 30,000 cph
- →Jaw 2:2 Heavy Duty — two sets of nipping rollers, 8 webs, 36,000 cph
- →Tucker — heavy-duty with balloon former, 10 webs, 50,000 cph
- →X-Press 1:2:2 — flagship advanced folder, 12 webs, 50,000 cph
- →Dynamically-balanced RTF, cutting and jaw cylinders across the range
- →Pneumatic RTF trolley tyres and air formers (Heavy Duty and up)
- →Options: 1/4 page folder, cross perforator, slitter on nipping rollers, upper former, fly-wheel delivery, cut-off compensator
Specifications
Models5 (1:2 Standard · 1:2 Super · 2:2 Heavy Duty · Tucker · X-Press 1:2:2)
Max Speed50,000 cph (Tucker, X-Press 1:2:2)
Max Webs12 (X-Press 1:2:2)
ApplicationsBroadsheet / Tabloid folding for web-offset presses
Performance of the machine may vary depending on a number of factors including substrate type, application, operator skill etc.
