Orient Jet C-Series
Digital Inkjet Printing — Aqueous
Production-grade aqueous inkjet press for book, commercial, newspaper, and security printing. Mono or 4-colour CMYK variants with simplex or duplex printing, custom high-end Piezo DOD print heads engineered exclusively for Orient, and in-line finishing for sheeting, folding, perforation, and perfect binding.
Maximum SpeedUp to 100 m/min @ 600 × 600 dpi · 80 m/min @ 1200 × 1200 dpi
Key Features
- →Custom high-end Piezo DOD inkjet print heads — long-lasting service life, engineered and manufactured exclusively for Orient
- →Mono or 4-colour CMYK · simplex or duplex printing
- →600 × 600 dpi and 1200 × 1200 dpi variants (optional 1200 × 900 @ 120 m/min · 1200 × 600 @ 150 m/min)
- →IR and hot-air drying
- →Orient Jet aqueous ink — open system, no proprietary lock-in
- →Full VDP: barcodes, QR codes, serialization, security elements
- →Web cleaner, anti-static, fully-servo tension control, web aligner, splice table, web-break sensor
- →Hybrid-ready with Orient X-Press Flex for inline priming, coating, and finishing
- →Harlequin RIP with HP/Dell server; custom Orient Jet software
Specifications
Printing TechnologyAqueous Inkjet Digital
Colour ConfigurationMono or 4-Colour CMYK · Simplex / Duplex
Resolution600 × 600 dpi or 1200 × 1200 dpi
Print SpeedUp to 100 m/min @ 600 × 600 dpi · 80 m/min @ 1200 × 1200 dpi
Machine Width330 – 1,200 mm (standard common web width 550 mm)
Imaging Width324 – 1,180 mm (standard common imaging widths 432 mm and 540 mm)
Substrate TypesUncoated & coated paper, newsprint, bond, offset, book-grade
Substrate Weight40 – 250 gsm (higher configurable with thickness kit)
InkOrient Jet Aqueous
Print HeadsCustom Piezo DOD · Industrial (exclusive to Orient)
DryingIR & Hot Air
Max Roll Diameter1,200 mm
FinishingIn-line sheeter, folder, rewinder, perforation, perfect binding
Environment40 – 60% RH, dust-free
Performance of the machine may vary depending on a number of factors including substrate type, application, operator skill etc.
